Capacity

Machine Capacity

Our maximum machine capacities are shown below. We regularly upgrade and update our machine tools so please feel free to contact us, we may be able to accommodate your project even if it does not appear to be the case from the dimensions given.

Turning

Diameter:

Over Bed                                21" (535mm)

Over Cross Slide                 14.5" (368mm)

In Gap                                     32" (810mm)


Between Centres:                80" (2000mm)

Milling

Table             12.75" x 51" (324 x 1295mm)


Travels:

X Axis                                      30" (760mm)

Y Axis                                      10" (254mm)

Z Axis                                   16.5" (420mm)


Spindle Nose to Table      18.625" (470mm)


Throat                                     14" (356mm)


Boring

Table          27.95" x 35.43" (710 x 900mm)


Travels:

X Axis                                   31.5" (800mm)

Y Axis                                 27.95" (710mm)

Z Axis                               41.75" (1060mm)

C Axis                                22.04" (560mm)


Diameters:

Facing                    Approx. 24.8" (630mm)

Boring                       Approx. 14" (550mm)

Tool, Cutter & Drill Grinding

We are able to sharpen lathe tools, milling cutters, reamers, taps, valve-seat cutters and twist drills, all in a variety of types and geometries, as well as other tooling not listed here. We can also manufacture or modify certain types of tooling if required. Please contact us with any enquiries you may have.
